The Millipore Automatic Sanitization Module (ASM) with IKA C-MAG HS 10 Hotplate Stirrer Set is a combined laboratory equipment set containing a Millipore Automatic Sanitization Module positioned together with an IKA C-MAG HS 10 laboratory hotplate magnetic stirrer. Both units are clearly identifiable in the photograph, with the upper unit labelled “Automatic Sanitization Module – MILLIPORE” and the lower blue unit corresponding to the IKA C-MAG HS 10 series.

The Millipore Automatic Sanitization Module is designed for use with compatible Millipore/Milli-Q purified-water storage reservoirs. It uses a 254 nm germicidal UV lamp to reduce bacterial proliferation and biofilm formation inside stored purified-water reservoirs. Millipore documentation describes ASM units for use with compatible storage tanks and water purification systems such as RiOs, Elix and related systems.

The lower instrument is an IKA C-MAG HS 10 hotplate magnetic stirrer. Published specifications for the C-MAG HS 10 include a chemically resistant ceramic/glass-ceramic heating surface, 100–1500 rpm stirring speed, 50–500 °C heating range, approximately 15 L maximum stirring capacity with water, and a 1500 W heater. The unit is designed for heating and magnetic stirring of laboratory samples.

The photographed equipment shows significant cosmetic wear, dirt, discoloration and signs of previous laboratory use. The Millipore ASM is shown physically positioned above the IKA stirrer, but the photograph alone does not establish that the two units are functionally compatible or designed to operate as one integrated system. They are therefore offered in this listing as the complete equipment set shown in the photograph, with compatibility and individual operation to be verified during refurbishment.

Applications

The Millipore Automatic Sanitization Module is used in laboratory water purification and storage systems where maintaining the microbiological quality of stored purified water is important. Its UV-based sanitization helps limit bacterial growth and biofilm formation inside compatible water-storage reservoirs. Millipore documentation describes 254 nm UV illumination as the germicidal mechanism used by the ASM.

The IKA C-MAG HS 10 is suitable for routine laboratory heating and magnetic stirring applications, including chemical preparation, solution mixing, dissolution, synthesis, sample preparation and other procedures requiring controlled heating and agitation. Its large ceramic heating surface and high stirring capacity make it suitable for larger laboratory vessels and batches.

Main Features

• Millipore Automatic Sanitization Module
• Integrated 254 nm germicidal UV technology
• Designed for compatible purified-water storage reservoirs
• Helps limit bacterial growth and biofilm formation
• IKA C-MAG HS 10 hotplate magnetic stirrer
• Ceramic/glass-ceramic chemically resistant heating surface
• Stirring speed up to approximately 1500 rpm
• Heating range approximately 50–500 °C
• Maximum stirring capacity approximately 15 L with water
• 1500 W heating output for documented C-MAG HS 10 configuration
• Suitable for laboratory heating, mixing and sample preparation

Technical Specifications

Millipore's ASM documentation confirms the use of a 254 nm UV lamp for germicidal protection of stored purified water. Specific ASM models vary by compatible storage tank/system, so the exact catalogue number of the photographed ASM should be verified from its rating or identification label.

For the IKA C-MAG HS 10, published specifications list 100–1500 rpm, 50–500 °C, approximately 15 L stirring capacity, a 280 × 280 mm platform for one documented version, and 1500 W heater output. Dimensions and electrical configuration can vary by version, so the rating plate of the photographed unit should be checked before installation.

Benefits of Refurbished Laboratory Equipment

Purchasing this refurbished laboratory equipment set can provide laboratories with useful scientific instrumentation at a lower acquisition cost compared with purchasing equivalent new equipment. The Millipore ASM can be valuable for laboratories maintaining compatible purified-water storage systems, while the IKA C-MAG HS 10 provides a robust platform for routine heating and magnetic stirring applications.

Refurbished equipment can be particularly useful for research laboratories, educational institutions, pharmaceutical facilities, chemical laboratories and laboratories maintaining existing or legacy equipment. Proper refurbishment and testing should include electrical inspection, control verification, heater and stirrer testing, UV-lamp inspection where applicable, and confirmation of the individual units' operating performance.

Additional Information

This listing represents the complete set shown in the photograph, consisting of the Millipore Automatic Sanitization Module and IKA C-MAG HS 10 Hotplate Magnetic Stirrer. The two instruments are physically shown together but should be treated as separate laboratory devices unless their intended integration is specifically confirmed.

The exact Millipore ASM catalogue number cannot be reliably determined from the visible front panel alone. Millipore offers several ASM configurations for different water purification and storage systems, including systems using 30, 60, 100 L and larger compatible reservoirs.

The equipment has visible cosmetic wear, dirt and discoloration from previous use. Accessories, cables, temperature probes, UV lamps, reservoir fittings, magnetic stir bars and other consumables are included only if specifically shown or stated. The buyer should verify the exact model, electrical voltage, accessories and compatibility before purchase.
